Returns the alarm status of the unit, where:
OK = no fault condition,
FT = faulted,
AL = alarm,
YS = Yes,
NO = No,
MS = masked,
?? = invalid due to hardware failure,
NA = not applicable because hardware/options not installed.
Example:
<1/RAS?’cr’
>0001/RAS=’cr’
P24V1=OK’cr’ +24V power supply
P24V2=OK’cr’ +24V switch pwr supply
LNBVT=OK’cr’ +13/18V LNB power supply
P13VT=OK’cr’ +13.5V power supply
P10V1=OK’cr’ +10V power supply
A10V1=OK’cr’ +10V1 RF supply
A10V2=OK’cr’ +10V2 RF supply
P7V8T=OK’cr’ +7.8V power supply
P5V8T=OK’cr’ +5.8V power supply
P2V5T=OK’cr’ +2.5V power supply
P1V2T=OK’cr’ +1.2V power supply
N5V8T=OK’cr’ -5.8V power supply
FANR1=OK’cr’ Fan 1 speed
FANR2=OK’cr’ Fan 2 speed
ATEMP=OK’cr’ Amplifier temperature
SHTDN=OK’cr’ Over-temp shutdown
IICST=OK’cr’ I2C bus status
FWPWR=OK’cr’ Forward power in dBm
CHKSM=OK’cr’ Flash checksum
FPGAD=OK’cr’ FPGA done status
BUCLD=OK’cr’ BUC lock detect
REFLD=OK’cr’ Reference lock detect
LNBCS=OK’cr’ LNB current status
SWITC=OK’cr’ Waveguide switch position status
RDLNK=OK’cr’ Redundant link status
TRMST=YS’cr’’lf’ Terminal Status
Note: LNBVT, A10V1, A10V2, FANR1, FANR2, BUCLD, REFLD, LNBCS, SWITC and RDLNK will only appear
