LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Serial-based Remote Product Management MN-LPOD
5–27
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Reboot
RBT=
1 byte
Command only.
Performs a soft reboot in the form x, where:
1 = Reboot System
RBT =
RBT?
RBT*
N/A
RBT=x
(See Description of
Arguments)
Retrieve
Configuration
Status
N/A
45 bytes
Query only.
Returns the configuration status of the unit.
Examples:
RCS=’cr’
ATT=12.75’cr’
AMP=1’cr’
MUT=1’cr’
ONL=1’cr’
ESW=1’cr’
AOF=00.00’cr’
AFR=1’cr’
XRF=N/A’cr’’lf’ (see Note)
Where:
ATT= attenuation in dB
AMP= RF power amplifier state, 0=OFF, 1=ON
MUT=RF mute state, 0=un-muted, 1=muted
RED=Online status for redundancy
ESW=Redundancy state and mode,
states: 0=OFF, 1=ON Tx only, 2=ON Tx & Rx
AOF=Attenuator Offset in dB
AFR= auto fault recovery, 0=manual, 1=auto
XRF = External reference status, N/A = no external reference, 05M for 5 MHz, and 10M for a 10 MHz
Note: XRF will always be N/A if the internal reference oscillator option is not installed.
RCS=
RCS?
RCS=x….x
(See Description of
Arguments)
Online Status
RED=
1 byte
Command or Query.
Sets or returns Redundancy Online status in the form x, where:
0 = Offline
1 = Online
Note: this command is functionally identical to the ONL command.
Example: <1/RED=1’cr’
>0001/RED=’cr’’lf’
RED=
RED?
RED*
RED?
RED=x
