Condair CP3 - 3.3 Steam humidifier construction

10
3.3 Steamhumidierconstruction
 1 Housing(small,large)
2 Cable openings, top side
3 Main contactor
 4 Powerboard
 5 ControlboardwithCP3Card
 6 Displayandcontrolunit
 7 Remoteoperatingandfaultindicationboard
8 Operation status indicators
 9 Cableopenings,bottomside
10 Drainkey
11 Unitswitch
12 Steam outlet
13 Water cup
14 Filling hose
15 Water supply hose
16 Inlet valve
17 Overowhose
18 Drainconnection(notvisible)
19 Watersupplypipe
20 Drainpump
21 Type plate
22 DataplateCP3Card
23 Steam cylinder
24 Levelsensor
25 Auxiliary drain hose
26 Electrode plug
The illustration above shows the large unit
1
12
13
15
14
17
16
19
18
20
23
25
26
24
2
3
7
4
5
6
8
11
10
9
22
21
