Condair CP3 - 3.8.2 Accessory details

17
Thesteamdistributionpipesareselectedonthebasisoftheduct width(forhorizontalinstallation)
or the duct height(forverticalinstallation)andthecapacityofthesteamhumidier.
Important! Alwaysselectthelongestpossiblesteamdistributionpipe(optimumhumidicationdistance).
3.8.2 Accessory details
3.8.2.1 Steam distribution pipe 41-.../61-.../81-...
3.8.2.2 OptiSorp steam distribution system
TheOptiSorpsteamdistributionsystemisusedinventilationductswithashorthumidicationdistance
(forthecalculationofthehumidicationdistancerefertochapter5.4.2).WhenorderinganOptiSorp
systemtheductdimensionmustbespecied.Pleaseconsultthedatainthefollowingtable.
Steam distribution pipes for
Condair CP3
1)
Length (L) steam
distribution pipe
Duct width (B)
Type 41-.. Type 61-.. Type 81-.. in mm
2)
in mm
41-200
200 210...400
41-350 61-350 81-350
3)
350 400...600
41-500 61-500 81-500
3)
500 550...750
41-650 61-650 81-650 650 700...900
41-800 61-800 81-800 800 900...1100
41-1000 61-1000 81-1000 1000 1100...1300
41-1200 61-1200 81-1200 1200 1300...1600
61-1500 81-1500 1500 1600...2000
61-1800 81-1800 1800 2000.2400
61-2000 81-2000 2000 2200...2600
81-2300 2300 2500...2900
81-2500 2500 2700...3100
1)
Material: CrNi steel
3)
up to max. 30 kg/h steam capacity
2)
special length on request
Note
:Ifthehumidicationdistance(seechapter5.4.2)hastobereducedfortechnicalreasons,the
amountofsteamperbasicunitmustbedividedbetweentwo steam distribution pipes or the steam
distribution system OptiSorpmustbeused.Ifthisisthecase,contactyourCondairsupplier.
OptiSorp Number of steam
connectors
Max. steam
capacity in kg/h
1)
Duct dimensions
Width in mm Height in mm
System 1 1 45 (30) 450-2700 450-1650
System 2 2 90 (60) 450-2700 450-2200
System 3 3 135 (90) 450-2700 800-3200
System 4 4 180 (120) 450-2700 800-3200
1)
For duct widths <600 mm the values in brackets apply
