Condair CP3 - 3.2 Identification of the unit

9
3.2 Identicationoftheunit
Theidenticationoftheunitisfoundonthetypeplate(forthelocationofthetypeplateseeunit
overview):
Condair AG, CH-8808 Pfäfkon
Type: CP3 Pro 45 Ser.Nr.: XXXXXXX 11.06
Heating Voltage: 400V / 3~ / 50...60Hz Power: 33.8 kW
Steam Capacity: 45.0 kg/h Ctrl.Voltage: 230V / 1~ / 50...60Hz
Water Pressure: 1...10 bar Model: Main Unit / Modul A
Made in Switzerland
Type designation Serialnumber(7digits) Month/Year
Heating voltage
Maximum steam capacity per unit
Admissible water supply pressure
Powerconsumption
Model
Control voltage
Fieldwithcerticationsymbols
