Condair CP3 - 10 Product specifications; 10.1 Technical data

76
10 Productspecications
10.1 Technical data
Heating voltage 230V/1~/50..60Hz
Unit model:
Basic Pro
5...8
Steam capacity in kg/h: 5...8
Max. power consumption in kW 3.8...6.0
Heating voltage 230V/3~/50..60Hz
Unit model:
Basic Pro Basic Pro Basic Pro Basic Pro Basic Pro Pro Pro
5...8 9...15 16...21 22...30 44/50/60 75/90 100/120
Steam capacity in kg/h: 5...8 9...15 16...21 22...30 44/50/60 75/90 100/120
Max. power consumption in kW 3.8...6.0 6.8...11.3 12.0...15.8 16.5...22.5 33.0/37.6/45.0 56.5/76.5 75.0/90.0
Heating voltage 400V/3~/50..60Hz
Unit model:
Basic Pro Basic Pro Basic Pro Basic Pro Basic Pro Pro Pro
5...8 9...15 16...25 26...45 52/60/70/80/90 105/120/135 152/160/180
Steam capacity in kg/h: 5...8 9...15 16...25 26...45 52/60/70/80/90 105/120/135 152/160/180
Max. power consumption in kW 3.8...6.0 6.8...11.3 12.0...18.8 19.5...33.8 39.0...67.5 78.8...101.3 114.0...135.0
Control voltage 1 x 230V / 50-60 Hz 2 x 230V / 50-60 Hz
Operating conditions
Admissible water pressure 1...10 bar
Water quality Untreated drinking water with a conductivity of 125...1250 uS/cm
Admissible water temperature 1...40 °C
Admissible ambient temperature 1...40 °C
Admissible ambient humidity max. 75% rh (non-condensing)
Admissible duct air pressure -0.8 kPa...1.5 kPa; overpressure kit (option) up to 10.0 kPa
Type of protection IP 20
Conformity CE, VDE, GOST
Dimensions/Weights
Housing (WxHxD) in mm 456x620x280 1 1 1 1
559x667x350 1 1 1 1 2 2 3 4
Net weight in kg 21 21 21 21 28 28 28 28 2x 28 2x 28 3x 28 4x 28
Operating weight in kg 26
26 32 32 65 65 65 65 2X 65 2X 65 3X 65 4x 65
Equipment/options
Steam cylinder type
(Type A.. standard equipment)
A3.../D3... 1 1
A4.../D4... 1 1
A6.../D6... 1 1 1 1 2 2 3 4
Steam hose connector SC22 1 S
SC60 1 S
SC80 1 S 1 S 2 S S S
Steam hose connector
with condensate trap
SCCT22 1
SCCT60 1
SCCT80 1 1 2
Condensate trap CT22 1
CT60 1
CT80 1 1 2 3 4
Cable gland PG 1 S 1 S 1 S 1 S 1 S S S
Overpressure set OPS 1 1 1 1 1 1 1 1 2 2 3 4
Remote operating and fault indication RFI 1 S 1 S 1 S 1 S 1 S S S
Terminals heating voltage
M-THV 1 S 1 S
L-THV 1 S 1 S 2 S S S
Mounting prole MP 1 1 1 1
1 1 1 1 1 1 3 4
Internal control voltage with terminals
M-CVI 1 1 1 1
L-CVI 1 1 1 1 1 1 2 2
Transformer 400V/230V
M-Trafo 1 1 1 1
L-Trafo 1 1 1 1 1 1 2 2
Housing front cover, stainless steel
M-INOX 1 1 1 1
L-INOX 1 1 1 1 2 2 3 4
Accessories
Steam distribution pipe 41-... 1 1
61-... 1 1
81-... 1 1 1 1 2 2 3 4
Steam distribution system OptiSorp System 1 1 1 1 1 1 1 1 1
System 2 1 1
System 3 1
System 4 1
Fan unit
FAN3S CP ... M 1 1 1 1
FAN3S CP ... L 1 1 1 1 2 2 3 4
Steam hose / meter DS22 1 1
DS60 1 1
DS80 1 1 1 1 2 2 3 4
Condensate hose / meter KS10 1 1 1 1 1 1 1 1 2 2 3 4
