6 Operation
Display and control unit
Function: CongurationoftheCondairCP3.
   Indicationofoperatingparameters.
   Resetofmaintenancecounteranderrorindication.
red LED “Error”
Function: TheLEDlightsincaseofamalfunctionoftheunit.The
typeofmalfunctionisshowninthedisplay,seechap-
ter8).
 TheLEDashesalternatelywiththegreenLEDifthe
externalsafetychain(ventilationinterlock,safetyhumi-
distat,etc.)isopen.
yellow LED “Warning”
Function: TheLEDlightsifthecylindermaintenanceisdue.
green LED “Steam”
Function: TheLEDlightsiftheunitproducessteam.
   TheLEDashesalternatelywiththeredLEDifthe
externalsafetychain(ventilationinterlock,safety
humidistat,etc.)isopen.
Drain key
Function: Manualdrainingofthesteamcylinder.Afterhaving
pressedthedrainkey,thedrainingiscontrolledvia
the display and control unit.
Unit switch
Function: Switchestheunitonandoff.Theswitchisilluminated
when the unit is running.
6.1 Function of the display and operating elements
6.2 Commissioning
Proceedasfollowswhenputtingtheunitintooperation:
1. Examinethesteamhumidierandinstallationforpossibledamage.
DANGER!
Damageddevicesordeviceswithdamagedinstallationmaypresentdangertohumanlifeor
cause severe damage to material assets.
Damaged units and/or units with damaged or faulty installation must not be operated.
2. Checkwhetherthefrontpanelismountedandxedwiththetwoscrews.
3. Open the ltervalve(ortheshut-offvalve,respectively)inthewatersupplyline.
4. Verifythesethumidityvalueatthehumiditycontrolleroratthehumidistat,andreadjustasre-
quired.
5. Switch on the service switchesformainssupplies(heatingandcontrolvoltage).
