Condair CP3 - 3.5 Humidification system overview

12
3.5 Humidicationsystemoverview
 1 Steamhumidier
2 Steam connection
3 Water drain connection
4 Water supply connection
 5 Filtervalve(accessory“Z261”)
 6 Manometer(installationrecommended)
 7 Funnelwithsiphon(buildingside)
 8 Waterdrainhose(accessory“DS80”
 9 Controlvoltagesupply
10 Heatingvoltagesupply
11 Cable openings
12 Steamhose(accessory“DS..”)
13 Condensatehose(accessory“KS10”)
14 Steam distribution pipe
  (accessory“41-..”/“61-..”/“81-..”)
15 Ventilationunit(accessory“FAN3S...”)
DS60
DS80
15
FAN3S CP Basic M
FAN3S CP Basic L
FAN3S CP Pro M FC
FAN3S CP Pro M
FAN3S CP Pro L
Basic
FAN3S CP Basic M FC
Basic
Pro
DS80
8
7
9
10
125...1250 µS/cm
1...10 bar
1...40 °C
1
2
3
4
5
6
Z261
14
11
KS10
61-..
41-..
81-..
13
DS60
DS22
DS80
12
