Example 1:
If it required that the drive must have an Enable, a Run Forward and a Run Reverse, then the value to set in parameter 6.41
is the addition of:
A hardware enable signal on terminal 9 is required to make this set up function correctly. Connect terminal 9 (Enable) to
terminal 7 (+24V).
Example 2:
If it required that the drive must have a Run, Not Stop and a Forward / Reverse, then the value set in parameter 6.41 is the
addition of:
A hardware enable signal on terminal 9 is required to make this set up function correctly. Connect terminal 9 (Enable) to
terminal 7 (+24V).
This parameter in conjunction with parameters 6.41 and 6.43 provides the means of controlling the drives Start/Stop functions
via serial communications.
Sending the correct control word to parameter 6.42 will allow the drive to be Enable, Run Forward, Run Reverse etc. This is
the binary code addition of the required operation of the drive.
From the examples in parameter 6.41:
Example 1
To Enable the drive, set parameter 6.42 = 1
To run the drive in the forward direction, set parameter 6.42 = 3
To run the drive in the reverse direction, set parameter 6.42 = 9
Example 2
To run the drive in the forward direction, set parameter 6.42 = 97
To run the drive in the reverse direction, set parameter 6.42 = 113
To stop the drive, set parameter 6.42 = 33
To disable the drive, set parameter 6.42 = 0
To enable the drive, set parameter 6.42 = 1
Binary Code Function
1 Drive Enable
2 Run Forward
8 Run Reverse
11 Value to set in parameter 6.41
Binary Code Function
1 Drive Enable
16 Forward / Reverse
32 Run
64 Not Stop
113 Value to set in parameter 6.41
6.42 Control word
Ú Ö
0 RW Uni
Binary Code Function
1 Drive Enable
2 Run Forward
8 Run Reverse
Binary Code Function
1 Drive Enable
16 Forward / Reverse
32 Run
64 Not Stop
NOTE
NOTE
