Appendix
NOTE: To facilitate connecting through modems, the [Menu] command times out after
three minutes of inactivity. To maintain a longer connection type: menu 1000
and press <ENTER>. The optional number is the amount in minutes that the
connection will be maintained. Typing [Menu 1000] essentially keeps the inter-
face alive until you cancel it.
9. You are now ready to communicate with the 1010 flow computer. But first, save your settings
by moving the mouse cursor to [File], sliding the cursor to [Save], then clicking [OK] on the
Save dialog box.
10. The next time you want to use HyperTerminal™:
Click on Start.
Drag to Programs.
Drag to Accessories. Drag to HyperTerminal, and click.
Double-click the icon you selected for the connection.
NOTE: For easier access, create a shortcut to the connect icon from your desktop. Right-
click on the icon to open its dialog box. Left-click on [Copy] and then move the
mouse cursor to a blank area on your desktop. Right-click to open dialog box
and then left-click on [Paste] to place a shortcut to the connect icon on your
desktop.
Accessing the Installation Menu
Once the parameters are set, HyperTerminal ™ automatically initiates Command mode. You
will see a blank screen.
Press ENTER a few times until you see [? For Help] on the screen.
Type: ? (question mark) and then press ENTER to see a list of the available commands.
Use the MENU command (type [Menu] and then press ENTER) to access the top level of the
Installation Menu. You will see a screen similar to the example on the next page.
Controlotron Site [1]
Select Meter Type
Meter Facilities
Meter Type Single Channel
To Next Page
