Dahua XVR5104HS User Manual

87
Model
Parameters
HCVR5404L-V2
HCVR5408L-V2
HCVR5416L-V2
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case,440mm（W）×410mm（D）×70mm（H）
Weight
4.5kg～5.5kg（exclude HDD）
Installation
Mode
Desk/rack installation
1.3.49 HCVR4224/32L-S2 Series
Model
Parameters
HCVR4224L-S2
HCVR4232L-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI:1～15f/s（The 1
st
/ 2
nd
channel supports 25/30f/s）
CVBS:1~25f/s（PAL）; 1~30f/s（NTSC）
Video Bit Rate
1024Kbps～4096Kbps,
For 720P realtime (The first two channels):default value is 2Mbps,max
value is 4Mbps.
For 720P non-realtime: default value is 1Mbps,max value is 2Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
24-ch, BNC port
32-ch, BNC port
Network Video
Input
Max 4 IPC connections（16Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,RCA port, Coaxible audio
4-ch,RCA port. Coaxible
audio

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
