Dahua XVR5104HS User Manual

52
Parameters
HCVR5104HE-S3
HCVR5108HE-S3
HCVR5116HE-S3
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
1.3.28 HCVR71XXHE-S3 Series
Parameters
HCVR7104HE-S3
HCVR7108HE-S3
HCVR7116HE-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps,
For 720P: default setup is 2Mbps,max supports 4Mbps.
For 1080P: default setup is 4Mbps,max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
