97
Model
Parameters
HCVR7104H-4M
HCVR7108H-4M
HCVR7116H-4M
record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Playback Channel
4-channel
8-channel
16-channel
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port
One HDD Space
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS485 port
USB
2 USB ports(One USB2.0 port at the front panel and one USB3.0 port
at the rear panel)
Others
Power
DC12V
Power
Consumption (No
HDD)
≤12W
≤13W
≤20W
Working
Temperature
-10~+55
Working Humidity
10%~90%
Dimensions
Mini 1U case, 325mmW×245mmD×45mmH
Weight No HDD
≤1.25KG
≤1.25KG
≤1.40KG
Installation Mode
Desk
1.3.54 HCVR72XXAN-4M Series
Model
Parameters
HCVR7204AN-4M
HCVR7208AN-4M
HCVR7216AN-4M
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264+/H.264
Encode
Resolution
Main stream:
2K(2560*1440)/1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF
Sub stream: D1/CIF/QCIF
Video Frame Rate
2K resolution: PAL:1~15f/s; NTSC:1~15f/s
Other resolutions: PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps,
For 720P: default setup is 2Mbps,max supports 4Mbps.
For 1080N: default setup is 4Mbps,max supports 6Mbps.
For 2K: non realtime default setup is 4Mbps,max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
