270
SN
Icon
Name
Note
Definition
Media
Interface
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device.
4
USB port
Connect to USB storage device, mouse, burning
DVD-ROM and etc.
5
Network port
1000M Ethernet port
6
VGA
VGA video
output
port
VGA video output port. Output analog video signal.
Can connect to the monitor to view ananlog video
output.
7
GND
Ground end
8
AUDIO
OUT
Audio output
port
Connect to video output device such as sound box.
9
A
RS485
(RS-485)
communicati
on port
RS485_A port. It is the cable A. You can connect to
the control devices such as speed dome PTZ.
B
RS485_B.It is the cable B. You can connect to the
control devices such as speed dome PTZ.
10
Power input
port
Input 12V DC.
11
Power switch
Power on/off button.
12
Power cable
fastener
Use clamp to secure the power cable on the device in
case there is any loss.
When connect the Ethernet port, please use crossover cable to connect the PC and use
the straight cable to connect to the switch or router.
2.3 Connection Sample
2.3.1 Smart Box Series
Please refer to Figure 2- 79 for connection sample.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua XVR5104HS and is the answer not in the manual?

Dahua XVR5104HS Specifications

General IconGeneral
Video CompressionH.265+/H.265/H.264+/H.264
Audio Input/Output1/1, RCA
Video Output1 HDMI, 1 VGA
Network Interface1 RJ-45 Port (100M)
Main ProcessorEmbedded Processor
Operating SystemEmbedded LINUX
Bit Rate32Kbps ~ 6144Kbps per channel
Operating Temperature-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input4+2 channel, each channel up to 6MP
Analog Video Input4 channel, BNC
USB Interface2x USB 2.0
HDD1 SATA port, up to 6TB
Dimensions260mm x 236mm x 48mm
HDCVI Camera Input4 channels
AHD Camera Input4 channels
TVI Camera Input4 channels
Operating Humidity10% ~ 90%
Resolution1080N, 720p, 960H, D1, CIF
Record RateUp to 25/30fps
