Dahua XVR5104HS User Manual

574
Figure 5- 111
Step 4 Click Save to complete the setup.
5.10.4.7 Quota
It is to set channel storage capacity.
CAUTION
HDD group and quota mode cannot be valid at the same time. System needs to restart
once you change the mode here.
Step 1 From main menu->Setup->Storage->Quota.
Enter quota interface. See Figure 5- 112.
Figure 5- 112
Step 2 Select a channel from the dropdown list and then select corresponding HDD
quota.
Step 3 Click Apply or Save to complete setup.
Step 4 Click Statistics to view HDD capacity you set for each channel.
5.10.5 Setting
5.10.5.1 General
The general interface includes general, date/time and holiday setup.
5.10.5.1.1 General
The general interface is shown as in Figure 5- 113.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
