1.3.37 HCVR72XXA-V2 Series
Model
Parameters
HCVR7204A-V2
HCVR7208A-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode Resolution
1080P /720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream
only)
Video Frame Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
2048Kbps-6144Kbps Kbps-4096Kbps,
For 1080P:default value is 4Mbps,max value is 6Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode Standard
G.711A, G.711U, PCM
Audio Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video Input
4-ch, BNC port
8-ch, BNC port
Network Video Input
Switch 2 analog channels to the IP channels（16Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,RCA port, audio via coaxial cable
Audio Output
1-ch,RCA port
Bidirectional Talk
Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm
record
Record Playback
Max 4-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
4-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V
Power Consumption
≤30W（exclude HDD）
Working Temperature
-10℃～＋55℃

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
