608
Figure 5- 164
Please refer to the following sheet for detailed information.
SN
Name
Function
1
Display
pan
It is to display human face detection file list. The latest file is at the
top. \
Click Export, you can export the selected file to the USB device.
There are two types: image/record.
Image: Export the recognized human face image.
Record: Export the record file before and after 10 seconds
when the DVR recognizes the human face.
2
Playback
pane
Play the searched record file or image. Double click to playback in full
screen.
3
Search
pane
Set date, start time and end time, click Search button, you can view the
corresponding file list.
5.14 Alarm
Click alarm function, you can see an interface is shown as Figure 5- 165.
Here you can set device alarm type and alarm sound setup (Please make sure you have
enabled audio function of corresponding alarm events.).
