Dahua XVR5104HS User Manual

347
4.4.12 Registration
Click , system goes to an interface for you to view remote device information. Please
refer to chapter 4.9.1.1.
4.4.13 Network
Click , system goes to the network interface. It is to set network IP address, default
gateway and etc. Please refer to chapter 4.9.2.
4.4.14 HDD Manager
Click , system goes to the HDD manager interface. It is to view and manage HDD
information. Please refer to chapter 4.9.4.2.
4.4.15 USB Manager
Click , system goes to the USB Manager interface. It is to view USB information,
backup and update. Please refer to chapter 4.7.3 Backup, chapter 4.8.4 Log, Chapter
4.9.5.12 Import/Export,, and chapter 4.9.5.14 Upgrade for detailed information.
4.5 USB Device Auto Pop-up
After you inserted the USB device, system can auto detect it and pop up the following
dialogue box. It allows you to conveniently backup file, log, configuration or update
system. See Figure 4-69. Please refer to chapter 4.7.3 Backup, chapter 4.8.4 Log,
Chapter 4.9.5.12 Import/Export,, and chapter 4.9.5.14 Upgrade for detailed information.
Figure 4- 69

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
