16
Parameters
HCVR4104C-S3
HCVR4108C-S3
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1
st
channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports( at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤7W
≤8W
Working
Temperature
-10~+55
Working
Humidity
10%~90%
Dimensions
SMART 1U case, 270mmW×205mmD×41mmH
Weight No
HDD
0.5KG
0.55KG
Installation
Mode
Desk
1.3.9 HCVR510XC-S3 Series
Parameters
HCVR5104C-S3
HCVR5108C-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps,
For 720P: default setup is 2Mbps,max supports 4Mbps.
For 1080P: default setup is 2Mbps,max supports 6Mbps.
