118
Parameters
XVR5104HS
XVR5108HS
XVR5116HS
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
N/A
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1
st
channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps
Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and
one at the rear panel)
1 USB2.0 port and
1 USB3.0 port
(One USB2.0 port
at the front panel
and one USB3.0
port at the rear
panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
7W
8W
10W
Working
Temperature
-10~+55
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mmW×220mmD×44mmH
Weight (No
HDD)
0.85KG
0.95KG
1.05KG
Installation
Mode
Desk
