40
Parameters
HCVR7104HE-V2
HCVR7108HE-V2
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mmW×245mmD×45mmH
Weight
1.25KGNo HDD
Installation
Mode
Desk
1.3.20 HCVR41XXHE-S2 Series
Parameters
HCVR4104HE-S2
HCVR4108HE-S2
HCVR4116HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/
HD1/2CIF/CIF/QCIF
720P(1~15fps)/960H/
D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:125f/sPAL;
1~30f/sNTSC
CVBS:1~25f/sPAL;
1~30f/sNTSC
HDCVI:1 15f/s The 1
st
channel
supports 25/30f
CVBS:1~25f/sPAL; 1~30f/sNTSC
Video Bit Rate
2048Kbps-4096Kbps,
For 720P: default setup
is 2Mbps,max supports
4Mbps.
For 960H: default
setup is 1Mbps,max
supports 3Mbps.
1024Kbps-4096Kbps,
For 720P: default setup is 1Mbps,max
supports 4Mbps.
For 960H: default setup is 1Mbps,max
supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel,BNC port
8-channel,BNC port
16-channel,
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
