71
Model
Parameters
HCVR4224AN-S2
HCVR4232AN-S2
Installation
Mode
Desk installation
1.3.40 HCVR52XXA-S2/HCVR5216AN-S2 Series
Model
Parameters
HCVR5204A-
S2
HCVR5208A-
S2
HCVR5216A-
S2
HCVR5216AN
-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P(1-15fps) /720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:1~25f/sPAL; 1~30f/sNTSC
CVBS:1~25f/sPAL; 1~30f/sNTSC
Video Bit Rate
2048Kbps-4096Kbps
For 1080P/720P:default value is 2Mbps,max value is 4Mbps
For 960H:default value is 1Mbps,max value is 3Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC
port
16-ch,
BNC
port
Network Video
Input
Max 2 IPC connections8Mbps
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,RCA port, audio via coaxial cable
Audio Output
1-ch,RCA port
Bidirectional
Talk Input
SupportReuse the audio port
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
