Dahua XVR5104HS User Manual

9
Parameters
HCVR7104C-V2
Talk Input
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤20W（With power adapter, no HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case,270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.4 HCVR410XC-S2 Series
Parameters
HCVR4104C-S2
HCVR4108C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/
2CIF/CIF/QCIF
720P(1~15fps)/960H/D1/
HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:1～25f/s（PAL）; 1~30f/s
（NTSC）
CVBS:1~25f/s（PAL）; 1~30f/s
（NTSC）
HDCVI:1 ～ 15f/s （ The 1
st
channel supports 25/30f）
CVBS:1~25f/s（PAL）; 1~30f/s
（NTSC）
Video Bit Rate
2048Kbps-4096Kbps,
For 720P: default setup is
2Mbps,max supports 4Mbps.
For 960H: default setup is
1Mbps,max supports 3Mbps.
1024Kbps-4096Kbps,
For 720P: default setup is
1Mbps,max supports 4Mbps.
For 960H: default setup is
1Mbps,max supports 3Mbps.
Bit Stream Type
Video stream/composite stream

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
