1.3.83 XVR7104HE-4KL/XVR7108HE-4KL/XVR7116HE-4KL Series
Working
Humidity
10%~90%
Dimension
1U case,
375mm*280mm*50mmW*D*H
Weight
No HDD
1.65KG
1.80KG
Installation
Mode
Desk installation
Model
Parameters
XVR7104HE-4KL
XVR7108HE-4KL
XVR7116HE-4KL
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
3840*2160@7fps/2592*1944@12fps/2560*1440@15fps/2048*153
6@15fps/1080P/720P/960H/D1/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s;NTSC:1~30f/s
Video Bit Rate
32Kbps12288Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support. (Sub-stream max supports 960H encode.)
Audio
Encode
Standard
G.711A, G.711U, PCM, AAC (AAC for the first channel only)
Audio
Sampling Rate
8KHz, 16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI/AHD/TVI/C
VBS self-adaptive)
8-ch BNC port
(HDCVI/AHD/TVI/C
VBS self-adaptive)
16-ch BNC port
(HDCVI/AHD/TVI/C
VBS self-adaptive)
