Page #179 background imageLoading...
Page #179 background image
163
Parameters
XVR5104C-S2
XVR5108C-S2
Connection
bandwidth:0Mbps-24Mbps
connections
Connection
bandwidth:0Mbps-48Mbp
s
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio Input
4-channel
8-channel
Audio Output
1-channel RCA port.
Bidirectional Talk
Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Playback Channel
4-channel
8-channel
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
RS485
Communication
N/A
USB
2 USB2.0 ports( at the rear panel)
Others
Power
DC12V
Power Consumption
(No HDD)
≤7W
≤8W
Working
Temperature
-10℃～＋55℃
Working Humidity
10%~90%
Dimensions
SMART 1U case, 270mm（W）×205mm（D）×41mm（H）
Weight （No HDD）
≤0.5KG
≤0.55KG
1.3.88 XVR41XXHS-S2 Series
Parameters
XVR4104HS-S2
XVR4108HS-S2
XVR4116HS-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
H.264
