1.3.5 HCVR510XC-S2 Series
Parameters
HCVR5104C-S2
HCVR5108C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P(1~15fps) /720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:125f/sPAL; 1~30f/sNTSC
CVBS:1~25f/sPAL; 1~30f/sNTSC
Video Bit Rate
2048Kbps-4096Kbps,
For 1080P/720P: default setup is 2Mbps,max supports 4Mbps.
For 960H: default setup is 1Mbps,max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel,BNC port
8-channel,BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
4T
