Dahua XVR5104HS User Manual

457
Figure 4- 196
4.9.5 System
4.9.5.1 General
4.9.5.1.1Device
General setting includes the following items. See Figure 4- 197.

Device ID: Please input a corresponding device name here.

Device No: Here you can set device number.

Language: System supports various languages: Chinese (simplified), Chinese
(Traditional), English, Italian, Japanese, French, Spanish (All languages listed here
are optional. Slight difference maybe found in various series.)

Video standard: There are two formats: NTSC and PAL.

Instant playback: It is to set playback time you can view in the preview interface. The
value ranges from 5 to 60 minutes.

Auto logout: Here is for you to set auto logout interval once login user remains
inactive for a specified time. Value ranges from 0 to 60 minutes.

Monitor channels when logout: Here you can set channels you want to view when
your account has logged out. Click the button and then cancel the channel name box,
you need to login to view the corresponding video. The channel window displays
in preview interface.

IPC Time Sync: You can input an interval here to synchronize the DVR time and IPC
time.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
