169
Parameters
XVR5104H-S2
XVR5108H-S2
XVR5116H-S2
Bidirectional
Talk Input
SupportReuse the audio port of the 1st channel
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Playback
Channel
4-channel
8-channel
16-channel
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps
Ethernet port
RS485
Communication
1 RS485 port
USB
2 USB2.0 ports(One at the front panel and one
at the rear panel)
1 USB2.0 port
and 1 USB3.0
port (One
USB2.0 port at
the front panel
and one USB3.0
port at the rear
panel)
Others
Power
DC12V
Power
Consumption
7W
8W
10W
Working
Temperature
-10~+55
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mmW×245mmD×45mmH
Weight
1.1KG
1.25KG
1.45KG
Installation
Mode
Desk
1.3.91 XVR51XXHE-S2 Series
Parameters
XVR5104HE-S2
XVR5108HE-S2
XVR5116HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
H.264

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua XVR5104HS and is the answer not in the manual?

Dahua XVR5104HS Specifications

General IconGeneral
Video CompressionH.265+/H.265/H.264+/H.264
Audio Input/Output1/1, RCA
Video Output1 HDMI, 1 VGA
Network Interface1 RJ-45 Port (100M)
Main ProcessorEmbedded Processor
Operating SystemEmbedded LINUX
Bit Rate32Kbps ~ 6144Kbps per channel
Operating Temperature-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input4+2 channel, each channel up to 6MP
Analog Video Input4 channel, BNC
USB Interface2x USB 2.0
HDD1 SATA port, up to 6TB
Dimensions260mm x 236mm x 48mm
HDCVI Camera Input4 channels
AHD Camera Input4 channels
TVI Camera Input4 channels
Operating Humidity10% ~ 90%
Resolution1080N, 720p, 960H, D1, CIF
Record RateUp to 25/30fps
