Dahua XVR5104HS User Manual

81
Model
Parameters
HCVR5216AN-S3
HCVR5232AN-S3
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
1-ch,RCA port
Coaxial Audio
Input
16-ch
32-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1
st
channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback, smart
playback
Record
Playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤10W
≤25W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
（no HDD）
≤1.8KG
Installation
Mode
Desk installation
1.3.46 HCVR72XXA-S3/HCVR7216AN-S3 Series

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
