72
Model
Parameters
HCVR5204A-
S2
HCVR5208A-
S2
HCVR5216A-
S2
HCVR5216AN
-S2
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm
input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V/4A
DC12V/
5A
Power
Consumption
≤30WNo HDD
Working
Temperature
-10℃~+55
Working
Humidity
10%~90%
Dimension
1U case,375mmW×280mmD×50mmH
Weight
1.5-2.5kgNo HDD
Installation
Mode
Desk installation
1.3.41 HCVR720XA-S2 Series
Model
Parameters
HCVR7204A-S2
HCVR7208A-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P /720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:1~25f/sPAL; 1~30f/sNTSC
CVBS:1~25f/sPAL; 1~30f/sNTSC
Video Bit Rate
2048Kbps-6144Kbps
For 1080P:default value is 4Mbps,max value is 6Mbps
For 720P:default value is 2Mbps,max value is 4Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
