Dahua XVR5104HS User Manual

98
Model
Parameters
HCVR7204AN-4M
HCVR7208AN-4M
HCVR7216AN-4M
Audio
Parameters
Encode Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI/CVBS)
8-ch BNC port
(HDCVI/CVBS)
16-ch BNC port
(HDCVI/CVBS)
Network Video
Input

Max add 2 IP
channel
connection.

Analog
/digital channel
switch. Max 6 IP
channel
connections

Connection
bandwidth:8Mbp
s-24Mbps

Max add 4 IP
channel
connection.

Analog
/digital channel
switch. Max 12
IP channel
connections

Connection
bandwidth:16
Mbps-48Mbps

Max add 8 IP
channel
connection.

Analog
/digital channel
switch. Max 24 IP
channel
connections

Connection
bandwidth:32Mbps-
96Mbps
Video Output
1-channel VGA output,
1-channel HDMI output, max 4K(3840*2160)@30f
HDMI/ VGA video output at the same time (of the same video source
or different video source).
Loop Output
N/A
Matrix Output
When the HDMI and VGA are outputting different video, system
supports one matrix output.
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
N/A
Audio Output
1-channel RCA port.
Bidirectional Talk
Input
Reuse the audio input/output port
Record
Record Mode
Schedule record/manual record/MD record/Alarm record/intelligent
record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Playback Channel
4-channel
8-channel
16-channel
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports
One HDD Space
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS485 port

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
