Parameters
XVR5104H
XVR5108H
XVR5116H
self-adaptive)
Network Video
Input

There is no IP
channel by
default. Max add
2 IP channel
connections

Analog
/digital channel
switch. Max 6 IP
channel
connections

Connection
bandwidth:0Mbp
s-24Mbps

There is no IP
channel by
default. Max add
4 IP channel
connections

Analog
/digital channel
switch. Max 12 IP
channel
connections

Connection
bandwidth:0Mbp
s-48Mbps

There is no IP
channel by
default. Max
add 8 IP
channel
connections

Analog
/digital
channel
switch. Max
24 IP channel
connections

Connection
bandwidth:0
Mbps-96Mbp
s
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
VGA/HDMI
optional
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
N/A
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps
Ethernet port

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
