Dahua XVR5104HS User Manual

114
Parameters
XVR2104HS
XVR2108HS
XVR2116HS
connection
 Analog
/digital channel
switch. Max 2 IP
channel
connections
 Connection
bandwidth:0Mb
ps-8Mbps
connection
 Analog
/digital channel
switch. Max 2 IP
channel
connections
 Connection
bandwidth:0Mb
ps-8Mbps
connection
 Analog
/digital channel
switch. Max 2 IP
channel
connections
 Connection
bandwidth:0Mb
ps-8Mbps
Video Output
1-channel VGA output,
1-channel HDMI output (of the same video source),
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
N/A
Coaxial Audio
Input
N/A
Audio Output
N/A
Bidirectional
Talk Input
N/A
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight （ No
≤1.25KG
≤1.35KG
≤1.45KG

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
