Dahua XVR5104HS User Manual

135
Network Video
Input
 There is no IP
channel by
default. Max
add 2 IP
channel
connections.
 Analog
/digital channel
switch. Max 6
IP channel
connections
 Connection
bandwidth:0Mb
ps-24Mbps
 There is no IP
channel by
default. Max
add 4 IP
channel
connections
 Analog
/digital channel
switch. Max 12
IP channel
connections
 Connection
bandwidth:0Mb
ps-48Mbps
 There is no IP
channel by
default. Max
add 8 IP
channel
connections
 Analog
/digital channel
switch. Max 24
IP channel
connections
 Connection
bandwidth:0Mb
ps-96Mbps
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
VGA/HDMI optional
Audio Port
External
Audio Input
1-ch,RCA port,
Coaxial Audio
Input
N/A
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1
st
channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
Communication
Port
Network
1 RJ45 port,
100Mbps Ethernet
port
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
