Dahua XVR5104HS User Manual

143
Video Port
Analog Video
Input
8-ch BNC port (HDCVI HD
video/general standard
definition video self-adaptive)
16-ch BNC port(HDCVI HD
video/general standard
definition video self-adaptive)
Network Video
Input
 Support 4 IP channels by
default.
 Analog
/digital channel
switch. Max 12 IP channel
connections.
 Connection
bandwidth:16Mbps-48Mbp
s
 Support 8 IP channels by
default.
 Analog
/digital channel
switch. Max 24 IP channel
connections.
 Connection
bandwidth:32Mbps-96Mbp
s
Video Output
1-ch VGA output,
2-ch HDMI output,
1-ch TV output,
HDMI1/VGA/TV video output at the same time (HDMI1/VGA/TV
of the same video source)
Loop Output
N/A
Matrix Output
HDMI2 port support matrix output
Audio Port
External
Audio Input
8-channel BNC port,
16-channel BNC port,
Coaxial Audio
Input
8-channel
16-channel
Audio Output
1-ch BNC port
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Card number record, mark record, alarm record, motion detection
record, regular record, manual record, intelligent record.
Playback Mode
Instant playback, normal playback, event playback, mark playback,
intelligent playback.
Record
Playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
16-channel
Alarm Output
6-channel
HDD
HDD Port
8 SATA ports. Support eSATA port.
Space/HDD
8T
Communication
Port
Network
2 RJ45 ports, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
4 USB ports (Two at the front panel and two at the rear panel. The
rear panel supports USB3.0)
Other
Power
AC100-240V 1.9A 50/60Hz

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
