Dahua XVR5104HS User Manual

158
Network Video
Input
 Support 0 IP
channel by
default.
 Max 6 IP
channels
connections
(Add 2 IP
channels and
4-channel
analog/digital
channel
switch.).
 Connection
bandwidth:
0Mbps-24Mbp.
 Support 0 IP
channel by
default.
 Max 12 IP
channels
connections
(Add 4 IP
channels and
8-channel
analog/digital
channel
switch.).
 Connection
bandwidth:
0Mbps-48Mbps.
 Support 0 IP
channel by
default.
 Max 24 IP
channels
connections
(Add 8 IP
channels and
16-channel
analog/digital
channel
switch.).
 Connection
bandwidth:
0Mbps-96Mbps.
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/VGA video output at the same time.
Loop Output
N/A
Matrix Output
Support (VGA/HDMI optional)
Audio Port
External
Audio Input
4-channel RCA port
Coaxial Audio
Input
4-channel BNC port
8-channel BNC port
16-channel BNC
port
Audio Output
1-channel RCA port
Bidirectional
Talk Input
Reuse audio input and output port of the first channel.
Record
Record Mode
Alarm record, motion detection record, regular record, manual
record, schedule record.
Playback Mode
Instant playback, normal playback, event playback, mark playback,
intelligent playback.
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-channel
16-channel
Alarm Output
3-channel
HDD
HDD Port
2 SATA ports
Space/HDD
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS485 port
USB
2 USB ports (One USB2.0 port at the front panel and one USB3.0
port at the rear panel. )

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
