Dahua XVR5104HS User Manual

326

HDD full: It is to select working mode when hard disk is full. There are two options:
stop recording or overwrite.
◇ Stop: If current HDD is full while there is no idle HDD, then system stops recording,
◇ Overwrite: If the current HDD is full while there is no idle HDD, then system
overwrites the previous files.
Note
DVR does not overwrite the locked files.

Pack duration: Here is for you to specify record duration. There are two ways for you
to set.
◇ Time length: It is to pack according to time. The value ranges from 1 to 60 minutes.
Default value is 60 minutes.
◇ File length: It is to pack according to file length. The default setup is 1024M. The
value ranges from 128M to 2048M.

Auto delete old files:
◇ Never: Do not auto delete old files.
◇ Customized: input customized period here, system can auto delete corresponding old
files.
Figure 4- 39
4.1.4.7 Schedule
Besides startup wizard and configuration wizard, from main
menu->Setting->Storage->Schedule, you can also go to the following interface.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
