Dahua XVR5104HS User Manual

505
Step 3 Select a camera to be initialized and then click Initialize button.
Device displays password setup interface. See Figure 5- 24.
Figure 5- 24
Step 4 Set camera password.

Using current device password and email: Check the box to use DVR
current admin account and email information. There is no need to set password
and email. Please go to step 7.

User name/password: The user name is admin. The password ranges from
8 to 32 digitals. It can contain letters, numbers and special characters (excluding
“'”,“"”,“;”,“:”,“&”) . The password shall contain at least two categories. Usually we
recommend the strong password.
WARNING
STRONG PASSWORD RECOMMENDED-For your device own safety, please
create a strong password of your own choosing. We also recommend you
change your password periodically especially in the high security system.
Step 5 Click Next button.
Enter input email interface. See Figure 5- 25.
Email: Input an email address for reset password purpose.
Note
Cancel the box and then click Next or Skip if you do not want to input email
information here.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
