Dahua XVR5104HS User Manual

516
Figure 5- 35
Please refer to the following sheet for detailed information.
Parameter
Function
Cover-area
Check Preview or Monitor first.
Click Set button, you can privacy mask the specified video in the preview or
monitor video.
System max supports 4 privacy mask zones.
Time Title
You can enable this function so that system overlays time information in
video window.
You can use the mouse to drag the time title position.
You can view time title on the live video of the WEB or the playback video.
Channel Title
You can enable this function so that system overlays channel information in
video window.
You can use the mouse to drag the channel title position.
You can view channel title on the live video of the WEB or the playback
video.
5.10.1.3.4 Path
The storage path interface is shown as in Figure 5- 36.
Here you can set snap image saved path ( in the preview interface) and the record
storage path ( in the preview interface).The default setup is C:\PictureDownload
and C:\RecordDownload.
Please click the Save button to save current setup.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
