Dahua XVR5104HS User Manual

528
Step 3 Double click a name to connect to it.
Click Refresh button, you can view latest connection status.
5.10.2.5 3G/4G
It is to connect to the 3G/4G network to receive alarm information, view device state,
audio/video and etc.
5.10.2.5.1 CDMA/GPRS
Step 1 From main window->Setup->Network->3G/4G.
Enter 3G/4G interface is shown as in Figure 5- 55.
Note
After you connected the 3G/4G module, you can view the module information and
wireless signal. If there is no information, click Search button to search.
Figure 5- 55
Step 2 Check the Boot up box to enable this function and then set parameters.
Parameter
Function
WLAN type
Here you can select 3G/4G network type to distinguish the
3G/4G module from different ISP. The types include
WCDMA,CDMA1x and etc.
APN/Dial No.
Here is the important parameter of PPP.
Authorization
It includes PAP,CHAP,NO_AUTH.
Pulse interval
It is to set time to end 3G/4G connection after you close extra
stream monitor. For example, if you input 60 here, system ends
3G/4G connection after you close extra stream monitor 60
seconds.
Important

If the pulse interval is 0, then system does not end 3G/4G connection
after you close the extra stream monitor.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
