Dahua XVR5104HS User Manual

535
Parameter
Function
Port mapping list
It is the same information on the UPnP list of the router.
 Service name:Defined by user.
 Protocol: Protocol type
 Internal port:Port that has been mapped in the router.
 External port:Port that has been mapped locally.
Note
 When you are setting the router external port, please use
1024~5000 port. Do not use well-known port 1~255 and the
system port 256~1023 to avoid conflict.
 When there are several devices in the same LAN, please arrange
the port mapping properly in case several devices are mapping to
the same external port.
 Please make sure the mapping port is available.
 For the TCP and UDP, please make sure the internal port and
external port are the same to guarantee the proper data
transmission.
Modify
Click ,you can change WAN port value.
Figure 5- 61
5.10.2.11 SNMP
Note
This function is for some series products only.
SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic
network management frame of the network management system. The SNMP widely used
in many environments. It is used in many network device, software and system.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
