Dahua XVR5104HS User Manual

538
Please follow the steps listed below to use this function.
Please set proxy server address, port, and sub-device name at the device-end. Please
enable the auto register function, the device can auto register to the proxy server.
Figure 5- 65
Parameter
Function
Server IP
address
The server IP address or server domain name you want to
register.
Port
The auto registration port value of the server.
Sub-device ID
The device ID allocated by the server.
5.10.2.14 Alarm Centre
The alarm center interface is shown as below. See Figure 5- 66.
This interface is reserved for you to develop. System can upload alarm signal to the alarm
center when local alarm occurs.
Before you use alarm center, please set server IP, port and etc. When an alarm occurs,
system can send out data as the protocol defined, so the client-end can get the data.
Figure 5- 66
Parameter
Function
Enable
Check the box to enable alarm center function.
Server IP
The IP address and the communication port of the PC that has installed
the alarm client.
Port
Self-report time
Select alarm upload time from the dropdown list.
5.10.2.15 P2P
You can use your cell phone to scan the QR code and add it to the cell phone client.
Via the SN from scanning the QR code, you can access the device in the WAN. Please

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
