Dahua XVR5104HS User Manual

542
Figure 5- 71
Figure 5- 72
Please refer to the following sheet for detailed information.
Parameter
Function
Enable MD
You need to check the box to enable motion detection function.
Please select a channel from the dropdown list.
Enable PIR
PIR function help enhance the motion detect accuracy and validity.
It is to filter the false alarm triggered by leaves, small fly and
insects. The PIR detection zone is smaller than the camera angle
of view.
The PIR function is enabled by default if the connected remote
device supports the PIR function. When the PIR function is on,
motion detection function is on by default. The motion detect event

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
