Dahua XVR5104HS User Manual

555

Support objects filter function.
Note:

The missing object detection function is valid once your network camera or your DVR
supports this function.

If you want to use the IVS function of the network camera, please make sure your
connected network camera supports this function.
Step 1 From main menu->Setup->Event->IVS, click to add the rule and select the
rule type as missing object detection.
Note
Double click to change a rule name.
Step 2 Check the missing object detection to enable missing object detection function.
See Figure 5- 84.
Figure 5- 84
Step 3 Click Draw rule button and then left click mouse to draw a zone. Right click
mouse to complete. See Figure 5- 85.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
