Step 2 Set parameters.
Parameter
Function
HDD full
It is to select working mode when hard disk is full. There are two options:
stop recording or rewrite.
 Stop: If current HDD is full while there is no idle HDD, then system
stops recording,
 Overwrite: If the current HDD is full while there is no idle HDD, then
system overwrites the previous files.
Note
DVR does not overwrite the locked files.
Pack
duration
It is to specify record duration. There are two ways for you to set.
 Time length: It is to pack according to time. The value ranges from 1
to 60 minutes. Default value is 60 minutes.
 File length: It is to pack according to file length. The default setup is
1024M. The value ranges from 128M to 2048M.
Auto
delete old
files

Never: Do not auto delete old files.
 Customized: input customized period here, system can auto delete
corresponding old files
5.10.4.2 Schedule
5.10.4.2.1 Schedule Record
In this interfaces, you can add or remove the schedule record setup. See Figure 5- 101.
There are three record modes: general (auto), motion detect and alarm. There are six
periods in one day.
You can view the current time period setup from the color bar.

Green color stands for the general record/snapshot.

Yellow color stands for the motion detect record/snapshot..

Red color stands for the alarm record/snapshot.

Blue color stands for MD&alarm record/snapshot.

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
