Dahua XVR5104HS User Manual

581
Figure 5- 120
Please refer to the following sheet for detailed information.
Parameter
Function
Enable
Check the box here to enable this function.
Interval
It is to set the interval from current channel group to the next
channel group.
Window split
Support 1-window split only.
Delete
Select a channel group and then click to delete it.
Up/Down
Click or to adjust channel tour sequence.
Add channel group
Click ,you can see system pops up the following dialogue box. See Figure 5- 121.
Please select the channels and then click OK button.
Figure 5- 121
Delete channel group

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
