Dahua XVR5104HS User Manual

597
Please refer to the following sheet for detailed information.
Parameter
Function
Import
It is to import the local setup files to the system.
Export
It is to export the corresponding WEB setup to your local PC.
5.10.5.12 Default
Note
This function is for admin user only.
The default setup interface is shown as in Figure 5- 146.
Here you can select Channel/Network/Event/Storage/System. Or you can check the All
box to select all items.
Figure 5- 146
5.10.5.13 Upgrade
CAUTION
 During the upgrade process, do not unplug the power cable, network cable, or
shutdown the device.
 Improper upgrade program may result in device malfunction!
There are two upgrade modes: file upgrade and online upgrade.
5.10.5.13.1.1 File Upgrade
The upgrade interface is shown as in Figure 5- 147.
Please select the upgrade file and then click the update button to begin update. Please
note the file name shall be as *.bin.
Figure 5- 147

Dahua XVR5104HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
Video Output	1 HDMI, 1 VGA
Network Interface	1 RJ-45 Port (100M)
Main Processor	Embedded Processor
Operating System	Embedded LINUX
Bit Rate	32Kbps ~ 6144Kbps per channel
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
IP Video Input	4+2 channel, each channel up to 6MP
Analog Video Input	4 channel, BNC
USB Interface	2x USB 2.0
HDD	1 SATA port, up to 6TB
Dimensions	260mm x 236mm x 48mm
HDCVI Camera Input	4 channels
AHD Camera Input	4 channels
TVI Camera Input	4 channels
Operating Humidity	10% ~ 90%
Resolution	1080N, 720p, 960H, D1, CIF
Record Rate	Up to 25/30fps
