Danfoss VLT AutomationDrive FC 300

A
A
99
3.9[ ]
153
6.0[ ]
0
0.0[ ]
225
8.9[ ]
45
1.8[ ]
0
0.0[ ]
286
11.2[ ]
0
0.0[ ]
R
S
T
A-A
130BC538.12
1
2
3
4
5
Figure 6.53 Terminal Locations, D6h with Contactor and Disconnect Options
1
Brake Terminals
2 TB6 Terminal block for contactor
3 Motor Terminals
4 Ground Terminals
5 Line Power Terminals
Table 6.26 Legend to Figure 6.53
Mechanical Installation Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 139
6 6
