Danfoss VLT AutomationDrive FC 300 - Page 150

176FA272.10
0[0.0]
55[2.2] 91[3.6]
139[5.5] 175[6.9]
0[0.0]
453[17.8]
B
A A A A
-R 81
9
19 Nm [14 FTa
Figure 6.62 IP21 (NEMA type 1) and IP54 (NEMA type 12) Enclosure Power Connection Positions (Detail B)
