Danfoss VLT AutomationDrive FC 300 - Page 168

2
1
176FA289.12
35
350
202.8
98.6
130.0
62.5
Figure 6.84 E1, Bottom View
1 Line Power Side
2 Motor Side
Table 6.51 Legend to Figure 6.84
1
130BA837.12
1328.8
(52.315)
595.8
(23.457)
533.0
(20.984)
36.2
(1.425)
281.8
(11.096)
535.0
(21.063)
216.5
(8.524)
37.7
(1.485)
460.0
(18.110)
668.3
(26.311)
593.0
(23.346)
199.5
(7.854)
258.5
(10.177)
35.5
(1.398)
Figure 6.85 F1, Bottom View
1 Cable conduit entry
Table 6.52 Legend to Figure 6.85
Mechanical Installation Design Guide
166 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG34S222
